MAP130 AC-DC Series Data Sheet
Features
?
?
?
?
?
?
?
?
?
RoHS lead-solder-exemption compliant
Automatic 115/230 input voltage selection
All outputs fully regulated
Remote sense, overvoltage protection, and
overtemperature protection
Power Fail signal included
Greater than 100,000 Hour MTBF
U-Channel chassis: 8.50" x 4.50" x 2.00"
(215.9mm x 114.3mm x 50.8mm)
Optional cover
Metric and SAE mounting inserts
Description
Power-One’s MAP130 Series of single and multiple output power supplies provide fully-regulated outputs with high
peak current capabilities in a compact 4.50" x 8.50" x 2.00" U-channel chassis. Other standard features include autos-
elect AC input, EMI level B filtering, power fail, thermal shutdown (with warning), remote sense, and metric and SAE
mounting inserts.
This convection-cooled series is designed for use in commercial and industrial environments in temperatures up to
50 °C. All products are approved to the latest international regulatory standards and display the CE Mark.
Single Output Model Selection
MODEL
OUTPUT
VOLTAGE
ADJUSTMENT
RANGE
CONTINUOUS
CURRENT
PEAK
CURRENT (NOTE 3)
LINE
REGULATION
LOAD
REGULATION
TYPICAL RIPPLE & INITIAL SETTING
NOISE %p-p (NOTE 1) ACCURACY
MAP130-1005
MAP130-1012
MAP130-1024
5V
12V/15V
24V/28V
4.75V to 5.50V
11.4V to 15.75V
22.5V to 30.0V
26A
12A/10A (Note 2)
6.2A/5.4A (Note 2)
30A
13.8A/11A
6.8A/5.9A
0.2%
0.2%
0.2%
1%
1%
1%
1%
1%
1%
5.1V to 5.2V
12.0V to 12.2V
23.9V to 24.1V
NOTES: 1) Typical peak to peak noise expressed as a percentage of output voltage, 20MHz bandwidth.
2) MAP130-1012 output currents are expressed as 12V/15V operation. MAP130-1024 output currents are expressed as 24V/28V operation.
3) Peak load for 60 seconds or less are acceptable, 10% duty cycle, maximum.
Multiple Output Model Selection – 130W Continuous Output Power
MODEL
OUTPUT
VOLTAGE
ADJUSTMENT
RANGE
OUTPUT
CURRENT
PEAK CURRENT
(NOTE 1)
LINE
REGULATION
LOAD
REGULATION
TYPICAL RIPPLE & INITIAL SETTING
NOISE %p-p (NOTE 2) ACCURACY
+5V
4.75V to 5.50V
20A
30A
0.2%
1%
1%
5.1V to 5.2V
MAP130-4000
MAP130-4001
MAP130-4002
+12V
-5V
-12V
+5V
+24V
-12V
+12V
+5V
+12V
-12V
+12V
11.5V to 12.5V
Fixed
Fixed
4.75V to 5.50V
23.0V to 25.0V
Fixed
Fixed
4.75V to 5.50V
11.5V to 12.5V
Fixed
Fixed
5A
1A
1A
20A
3.5A
1A
1A
20A
5A
1A
1A
10A
1A
1A
30A
5A
1A
1A
30A
10A
1A
1A
0.5%
0.5%
0.5%
0.2%
0.5%
0.5%
0.5%
0.2%
0.5%
0.5%
0.5%
2%
2%
2%
1%
2%
2%
2%
1%
2%
2%
2%
1%
1%
1%
1%
1%
1%
1%
1%
1%
1%
1%
11.75V to 12.0V
-4.8V to -5.2V
-11.6V to -12.4V
5.1V to 5.2V
23.9V to 24.1V
-11.6V to -12.4V
-11.6V to -12.4V
5.1V to 5.2V
11.9V to 12.1V
-11.6V to -12.4V
11.6V to 12.4V
Model numbers highlighted in yellow or shaded are not recommended for new designs.
MCD10115 Rev. 1.3, 05-Feb-10
Page 1 of 4
www.power-one.com
